Features
bullet1.5 - 12VDC
bulletSmall Size
bulletLow Current Drain

Model Operating
Voltage
Range
(VDC)
Rated
Voltage
(VDC)
Max.
Current
at Rated
Voltage
(mA)
Res.
Freq.
(KHz)
0.4
Min. Sound
Pressure @
Rated
Voltage
 (dBA/30cm)
Pulse Rate
@ Rated
 Voltage
(Pulses/
Second)
Tone Terminal
MB-1S1 1.3 - 2 1.5 20 2.3  75 NA Solid PCB Pins
MB-1S3 2 - 5 3 30 2.3  82 NA Solid PCB Pins
MB-1S6 4 - 7 6 30 2.3  85 NA Solid PCB Pins
MB-1S9 7 - 11 9 30 2.3  85 NA Solid PCB Pins
MB-1S12 8 - 15 12 30 2.3  85 NA Solid PCB Pins
Specifications and dimensions subject to change without notice.
