Home > Buzzers, Alarms & Sirens > Piezo Buzzers > PB-150

Features
bullet12 VDC
bullet2.5KHz Resonant Frequency
bullet Loud Output
bulletPCB Mount
Model Oper.
Voltage Range
(VDC)		 Rated
Voltage
(VDC)		 Max.
Current
@ Rated
Voltage (mA)		 Res.
Freq.
(KHz)±
0.5		 Min. SPL
@ Rated
Voltage
(dBA/
30cm)		 Pulse
Rate
@ Rated Voltage
(Pulses/
Second)		 Tone Terminal
PB-150S12 5 - 13 12 75 2.5  108 NA Single Pins
Specifications and dimensions subject to change without notice.
